Description

Powering Large-Scale Energy Solutions with Solis Three Phase 50kW High Voltage Hybrid Inverter

The Solis Three Phase 50kW High Voltage Energy Storage Hybrid Inverter is a high-performance solution for large-scale commercial and industrial energy systems. Designed for maximum flexibility and efficiency, this hybrid inverter seamlessly manages energy flow between solar panels, battery storage, and the grid, ensuring reliable and cost-effective power management.

Key Features

• High Power Output: Supports up to 50kW of power, making it ideal for large-scale energy systems.
• Hybrid Functionality: Balances solar energy, battery storage, and grid power for optimized energy use.
• High Voltage Battery Compatibility: Suitable for high-voltage battery banks, increasing efficiency and scalability.
• Four MPPTs (Maximum Power Point Tracking): Optimizes energy harvest by allowing flexible system design and operation under varying conditions.
• Smart Monitoring: Real-time monitoring and remote management via a built-in platform.
• IP65 Weatherproof Design: Reliable performance in harsh environments, suitable for indoor and outdoor installations.
• Advanced Protection: Built-in safety features to protect against overvoltage, overcurrent, and overheating.

Specifications

• Rated Power: 50,000 W
• Min PPT Voltage: 180 V
• Max PPT Voltage: 850 V
• DC Startup Voltage: 180 V
• DC Shutdown Voltage: 150 V
• Max Input Voltage: 1,000 V
• Max DC Power: 100,000 W
• Max AC Power (5 Minutes): 50,000 W
• Surge AC Power (1 Second): 80,000 W
• Max DC Current: 160 A
• Max DC Inputs: 8
• Has DC Fuses: No
• Connector Type: MC4
• Included Connectors: 8
• Euro Efficiency: 97.4 %
• Transformer: None
• MPPT Quantity: 4
• Has Integrated DC Switch: Yes
• Warranty: 5 Years
• Weight: 73 kg
• Supplier Part No: S6-EH3P50K-H-EU

Applications

• Commercial and Industrial Energy Systems
• Microgrids
• Large-Scale Solar and Storage Projects
• Backup Power Solutions

What’s Included

• Solis Three Phase 50kW High Voltage Hybrid Inverter
• User Manual & Installation Guide
• MC4 Connectors

Why You Should Buy the Solis Three Phase 50kW High Voltage Hybrid Inverter

• Unmatched Performance: With a 50kW rated power and a maximum DC power capacity of 100,000W, this inverter offers robust energy management for large-scale systems.
• High Compatibility: Supports a wide range of high-voltage battery storage solutions, ensuring seamless integration into existing or new energy systems.
• Advanced MPPT Technology: Equipped with 4 MPPTs, it efficiently captures and converts solar energy for optimal power output even under challenging conditions.
• Durability and Reliability: Designed for demanding environments with a high-efficiency rating of 97.4% and extensive safety features.
• Flexible System Design: With 8 DC inputs and no internal transformer, this inverter offers excellent system design flexibility for commercial and industrial installations.
• Future-Proof Investment: Comes with a 5-year warranty and upgradable firmware, ensuring your energy solution stays up-to-date and reliable for years to come.

Certifications:

• G99 Certified – Ensures compliance with UK grid connection standards for large-scale systems.
• EN 50549-1 – Grid connection requirements for generating units in low-voltage installations.
• CE Certification – Conforms to European safety, health, and environmental protection standards.
• IEC 62109-1 / IEC 62109-2 – Safety standards for power converters in renewable energy systems.

The Solis 50kW Hybrid Inverter offers a powerful and scalable energy solution for commercial applications, providing high efficiency, advanced safety features, and exceptional reliability for long-term performance.

Need More Information?

For further details, please refer to the attached datasheet and user manuals for comprehensive specifications, installation guidelines, and troubleshooting information.
