Description

SolaX X1 IES 6kW Single Phase Hybrid Inverter

Powerful and intelligent 6.0kW single-phase hybrid inverter designed for high-efficiency residential solar energy systems. The SolaX X1 IES 6kW offers 200% PV oversizing, triple MPPT tracking, and fast UPS-level switchover, making it a top-tier solution for integrating PV, battery storage, and backup power in a compact, all-in-one design.

Key Features

• 6kW rated hybrid inverter with triple MPPT

• All-in-one, plug-and-play design for easy installation

• Supports up to 200% PV input and 50A battery charge/discharge

• EPS output supports up to 2× power for 10 seconds

• Switchover time <10ms for uninterrupted power

• Advanced AI forecasting and VPP compatibility (OpenADR, IEEE2030.5, etc.)

• IP66-rated enclosure with fanless natural cooling

• Type II SPD protection on both AC and DC sides

• AFCI optional for enhanced safety

• Smart load management for EV chargers, heat pumps, etc.

Specifications

• Power Output: 6000W

• Cell Type: Hybrid

• Dimensions (W x H x D): 717 × 350 × 210 mm

• Weight: 26.2 kg

• Maximum Efficiency: 97.6%

• European Efficiency: 97.0%

• Operating Temperature Range: -35°C to 60°C (derating at >45°C)


• Ingress Protection: IP66

• Max. PV Input Voltage: 600V

• MPP Tracker Voltage Range: 50~600V

• Max. PV Input Current: 20A per MPPT (3 MPPTs)

• Nominal AC Voltage: 220 / 230 / 240 V

• Nominal Frequency: 50 / 60 Hz

• EPS Output Power: 6000W (2x for 10s)

• Switchover Time: <10ms

• Cooling: Natural cooling

• Communication Interfaces: RS485, CAN, Pocket-X, DO, DI

• Night Power Consumption: < 5W (cold), < 40W (hot standby)

• SKU: X1-IES-6K

Applications

• Advanced residential solar + battery systems

• Smart home integrations with EV and heat pump control

• Backup power for homes requiring high EPS performance

• Off-grid and micro-grid solutions

• Homes participating in virtual power plant (VPP) programs

Why Choose This Product

• High Performance: Delivers 6kW power with 3 MPPTs for flexible solar array design

• Smart Energy Control: AI forecasting and VPP-ready integration

• Robust Protection: IP66 housing, surge protection, and UPS-level backup

• All-in-One Simplicity: No external parts needed—just plug and play

• Future-Ready: Perfect for evolving home energy demands

What’s Included in the Box

• 1x SolaX X1 IES 6kW Hybrid Inverter

• Built-in LCD display

• WiFi or Pocket-X dongle (optional)

• User and installation manual
