Description

High-Performance 510W N-Type ABC Mono Dual Glass All Black Solar Panel

The Aiko Neostar 2S+ 510W All Black Solar Panel represents cutting-edge solar technology, combining N-Type ABC cells, dual-glass construction, and a premium black anodized frame. With an impressive module efficiency of 22.6%, this panel offers powerful energy generation and superior reliability, making it ideal for residential and commercial rooftop installations seeking maximum performance and sleek aesthetics.

Key Features

• High power output of 510W for enhanced energy generation
• Impressive module efficiency of 23%, maximising rooftop utilisation
• Durable dual-glass construction with 2.0mm semi-tempered coated glass
• Full black anodized aluminium frame for a premium aesthetic finish
• IP68-rated junction box with 3 bypass diodes for superior protection
• Advanced N-Type ABC cell technology for greater temperature tolerance and reliability
• Certified MC4-Evo2 connectors ensuring easy and secure installation
• Optimised for longevity with dual-glass design, reducing degradation over time


Specifications

• Rated Power (Pmax): 510 W
• Dimensions: 1954 × 1134 × 30 mm
• Weight: 27.2 kg (±3%)
• Front Glass: Dual 2.0 + 2.0 mm coated semi-tempered glass
• Frame: Black Anodized Aluminium
• Vmp (Voltage at Maximum Power): 38.10 V
• Imp (Current at Maximum Power): 13.39A
• Voc (Open Circuit Voltage): 45.22 V
• Isc (Short Circuit Current): 14.17 A
• Efficiency: 23%
• Connector Type: MC4-Evo2
• Junction Box: IP68 Rated, 3 Bypass Diodes
• Output Cables: 4.0 mm² (12AWG UL), Length ±1200 mm
• IEC Fire Type: Class C
• Protection Class: Class II
• Pallet Size: 37 pcs per pallet / 185 pcs per 20' GP / 888 pcs per 40' HC
• Cell Type: N-Type ABC
• No. of Cells: 120 (6×20)
• Supplier Part No: AIKO-A510-MAH60Db

What’s Included in the Box

• 1x Aiko Neostar 2S+ 510W N-Type Solar Panel
• Pre-installed MC4 EVO2 connectors for easy connection
• Installation and safety manual
• Protective packaging to ensure safe delivery

Applications

The Aiko Neostar 2S+ 510W N-Type Solar Panel is ideal for:

• Residential rooftop installations that require a high level of energy efficiency with a sleek, all-black design.
• Commercial properties looking for a combination of aesthetics and high-performance energy generation.
• Large-scale utility projects where space efficiency and high energy output are key priorities.

Why Choose the Aiko Neostar 2S+ 510W N-Type Solar Panel?

• High Energy Efficiency: With a 23% module efficiency, this panel maximises energy output even in space-constrained systems.
• Stylish Design: Its all-black appearance and black anodized frame ensure a sleek and modern look for any property.
• Robust Durability: Featuring dual-glass technology and an IP68-rated junction box, it offers superior resistance against environmental stresses.
• Sustainability: The dual-glass structure prolongs the panel's life, improving long-term performance and reducing overall system costs.
• Long Warranty: Backed by strong manufacturer warranties (typically up to 30 years for performance), giving peace of mind for long-term investments.


With its superior 22.6% module efficiency, N-Type ABC cells, and all-black dual-glass construction, the Aiko Neostar 2S+ 510W solar panel offers a perfect combination of high output, aesthetic appeal, and long-term reliability, making it a premium solution for homes and businesses aiming for energy independence.
